8mm End Cap without Stem
Cap diameter = 8mm + 0.00/-0.2mm
Taper angle = 60 degree +/-0.1 degree
Tapered end diameter = 1.8mm +/-0.2 mm
Cap length (without taper) = 14.6mm +/-0.2 mm
Total length = 20mm +/-0.2 mm
Clear aperture = >80% both ends
Surface flatness = ?/4 At 633nm at both ends
Surface quality = 20-10 (S-D)
Parallelism = 5 arc sec
Material = UV fused silica (corning 7980)
Coating = Uncoated
