A concave mirror is a spherical mirror with reflective surface curved inwards. Concave mirrors produce real and virtual images. These mirrors find applications in laser beam concentration and quality imaging. Holmarc’s concave mirrors have protected aluminium coating and offer high reflection throughout UV, visible and NIR region.
► Diameter : 50 mm
► Focal length : 300 mm
► Material : Borofloat ( schott )
► Thickness Tolerance : ± 0.2 mm
► Dimensional Tolerance : +0.00, -0.2 nm
► Clear aperture : 90 % of diameter
► Surface quality : 40 – 20 ( scratch-dig )
► Surface flatness : λ / 4 @ 632.8 nm
► Parallelism : ≤ 3 arc sec
► Coating : Protected aluminium
► Reflectivity Ravg : > 88% @ 450 nm – 2 μm,
> 93% @2 μm – 20 μm
► Damage threshold : < 200 mJ / cm2 ( @ 532 nm CW laser )
# Dispatch within 3 days
Model No: HO-CCMA-50-06
